PTV08040WAD دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت PTV08040WAD	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Power Modules
Datasheet: Texas Instruments PTV08040WAD
Output Channel: 1
Output Voltage: 0.8V~3.6V
Input Voltage(DC): 8V~14V
Output Current (Max): 50A
Conversion Efficiency: 95%
Package: -
Manufacturer: Texas Instruments
Series: PTV08040W
Type: Non-Isolated PoL Module
Voltage - Input (Min): 8V
Voltage - Output 3: -
Applications: ITE (Commercial)
Number of Outputs: 1
Package / Case: 21-DIP Module
Voltage - Output 2: -
Part Status: Active
Voltage - Input (Max): 14V
Mounting Type: Through Hole
Size / Dimension: 2.36" L x 0.37" W x 0.95" H (59.9mm x 9.4mm x 24.1mm)
Voltage - Output 1: 0.8 ~ 3.6V
Base Part Number: PTV080
Operating Temperature: -40°C ~ 85°C
Efficiency: 95%
Packaging: Tray
Current - Output (Max): 50A
Features: UVLO
detail: Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 3.6V 50A 8V - 14V Input
