دیتاشیت ADG1633BRUZ-REEL7

ADG1633,34

مشخصات دیتاشیت

نام دیتاشیت ADG1633,34
حجم فایل 445.002 کیلوبایت
نوع فایل pdf
تعداد صفحات 19

دانلود دیتاشیت ADG1633,34

ADG1633,34 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Switch Circuit: SPDT
  • Multiplexer/Demultiplexer Circuit: 2:1
  • Number of Circuits: 3
  • On-State Resistance (Max): 4.5Ohm
  • Channel-to-Channel Matching (ΔRon): 120mOhm
  • Voltage - Supply, Single (V+): 3.3V ~ 16V
  • Voltage - Supply, Dual (V±): ±3.3V ~ 8V
  • Switch Time (Ton, Toff) (Max): 38ns, 152ns
  • -3db Bandwidth: 109MHz
  • Charge Injection: -12.4pC
  • Channel Capacitance (CS(off), CD(off)): 19pF, 32pF
  • Current - Leakage (IS(off)) (Max): 100pA
  • Crosstalk: -64dB @ 1MHz
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 16-TSSOP (0.173", 4.40mm Width)
  • Supplier Device Package: 16-TSSOP
  • Base Part Number: ADG1633
  • detail: 3 Circuit IC Switch 2:1 4.5Ohm 16-TSSOP
