دیتاشیت AD5689BRUZ-RL7

AD5689/87

مشخصات دیتاشیت

نام دیتاشیت AD5689/87
حجم فایل 597.388 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

دانلود دیتاشیت AD5689/87

AD5689/87 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices AD5689BRUZ-RL7
  • Interface: SPI;DSP
  • resolution: 16
  • output type: Voltage-缓冲
  • built-up time: 8us
  • Supply Voltage: 1.8V~5.5V
  • Integral nonlinearity: ±1LSB
  • Operating Temperature: -40°C~+105°C
  • Package: TSSOP-16
  • Manufacturer: Analog Devices
  • Series: nanoDAC+®
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Number of Bits: 16
  • Number of D/A Converters: 2
  • Settling Time: 8µs
  • Differential Output: No
  • Data Interface: SPI, DSP
  • Reference Type: External
  • Voltage - Supply, Analog: 2.7V ~ 5.5V
  • Voltage - Supply, Digital: 1.8V ~ 5.5V
  • INL/DNL (LSB): ±1, ±1 (Max)
  • Architecture: String DAC
  • Package / Case: 16-TSSOP (0.173", 4.40mm Width)
  • Supplier Device Package: 16-TSSOP
  • Mounting Type: Surface Mount
  • Base Part Number: AD5689
  • detail: 16 Bit Digital to Analog Converter 2 16-TSSOP
