LF147, LF347 Datasheet

LF147, LF347

Datasheet specifications

Datasheet's name LF147, LF347
File size 1833.664 KB
File type pdf
Number of pages 24

Download Datasheet LF147, LF347

Download Datasheet

Other documentations

LF147, 347 24 pages

Technical specifications

  • Series: BI-FET II™
  • Package / Case: 14-DIP (0.300", 7.62mm)
  • Number of Circuits: 4
  • Current - Supply: 7.2mA
  • Voltage - Input Offset: 3mV
  • Mounting Type: Through Hole
  • Part Status: Obsolete
  • Slew Rate: 13V/µs
  • Voltage - Supply, Single/Dual (±): 8V ~ 36V, ±4V ~ 18V
  • Gain Bandwidth Product: 4MHz
  • Operating Temperature: 0°C ~ 70°C
  • Amplifier Type: J-FET
  • Manufacturer: Texas Instruments
  • Packaging: Tube
  • Base Part Number: LF347
  • Current - Input Bias: 50pA
  • Output Type: -
  • Supplier Device Package: 14-DIP
  • detail: J-FET Amplifier 4 Circuit 14-DIP
