دیتاشیت AD7564ARZ-BREEL

AD7564

مشخصات دیتاشیت

نام دیتاشیت AD7564
حجم فایل 474.294 کیلوبایت
نوع فایل pdf
تعداد صفحات 17

دانلود دیتاشیت AD7564

AD7564 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices AD7564ARZ-BREEL
  • Interface: SPI
  • Resolution: 12Bit
  • Output Type: Current-非缓冲
  • Settling Time: 3.5us
  • Supply Voltage: 3V~5.5V
  • Integral nonlinearity: ±1LSB;±0.9LSB
  • Operating Temperature: -40°C~+85°C
  • Package: SOP-28-300mil
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Number of Bits: 12
  • Number of D/A Converters: 4
  • Differential Output: Yes
  • Data Interface: SPI
  • Reference Type: External
  • Voltage - Supply, Analog: 3V ~ 5.5V
  • Voltage - Supply, Digital: 3V ~ 5.5V
  • INL/DNL (LSB): ±1 (Max), ±0.9 (Max)
  • Architecture: R-2R
  • Package / Case: 28-SOIC (0.295", 7.50mm Width)
  • Supplier Device Package: 28-SOIC
  • Mounting Type: Surface Mount
  • Base Part Number: AD7564
  • detail: 12 Bit Digital to Analog Converter 4 28-SOIC
