دیتاشیت ADUM3471WCRSZ-RL7

مشخصات دیتاشیت

دانلود دیتاشیت ADUM3470-74	ADUM3470-74 Datasheet

Manufacturer: Analog Devices Inc.
Series: Automotive
Packaging: Tube
Part Status: Active
Technology: Magnetic Coupling
Type: General Purpose
Isolated Power: No
Number of Channels: 4
Inputs - Side 1/Side 2: 3/1
Channel Type: Unidirectional
Voltage - Isolation: 2500Vrms
Common Mode Transient Immunity (Min): 25kV/µs
Data Rate: 25Mbps
Propagation Delay tpLH / tpHL (Max): 60ns, 60ns
Pulse Width Distortion (Max): 8ns
Rise / Fall Time (Typ): 2.5ns, 2.5ns
Voltage - Supply: 3V ~ 3.6V, 4.5V ~ 5.5V
Operating Temperature: -40°C ~ 105°C
Mounting Type: Surface Mount
Package / Case: 20-SSOP (0.209", 5.30mm Width)
Supplier Device Package: 20-SSOP
Base Part Number: ADUM3471
detail: General Purpose Digital Isolator 2500Vrms 4 Channel 25Mbps 25kV/µs CMTI 20-SSOP (0.209", 5.30mm Width)
