دیتاشیت ADP7159ACPZ-02-R7

ADP7159

مشخصات دیتاشیت

نام دیتاشیت ADP7159
حجم فایل 1065.044 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت ADP7159

ADP7159 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Adjustable
  • Number of Regulators: 1
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Min/Fixed): 1.2V
  • Voltage - Output (Max): 2.3V
  • Voltage Dropout (Max): 0.28V @ 2A
  • Current - Output: 2A
  • Current - Quiescent (Iq): 8mA
  • Current - Supply (Max): 14mA
  • PSRR: 61dB ~ 45dB (1kHz ~ 1MHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: 10-VFDFN Exposed Pad, CSP
  • Supplier Device Package: 10-LFCSP-WD (3x3)
  • Base Part Number: ADP7159
  • detail: Linear Voltage Regulator IC 1 Output 2A 10-LFCSP-WD (3x3)
