دیتاشیت ISO150AU

مشخصات دیتاشیت

دانلود دیتاشیت ISO150	ISO150 Datasheet

Type: General Purpose
Pulse Width Distortion (Max): 6ns
Rise / Fall Time (Typ): 9ns, 9ns
Base Part Number: ISO150
Voltage - Isolation: 1500Vrms
Operating Temperature: -40°C ~ 85°C
Package / Case: 28-SOIC (0.295", 7.50mm Width), 12 Leads
Voltage - Supply: 3V ~ 5.5V
Supplier Device Package: 12-SOP
Common Mode Transient Immunity (Min): 1.6kV/µs (Typ)
Series: -
Technology: Capacitive Coupling
Channel Type: Bidirectional
Propagation Delay tpLH / tpHL (Max): 40ns, 40ns
Part Status: Obsolete
Mounting Type: Surface Mount
Number of Channels: 2
Isolated Power: No
Manufacturer: Texas Instruments
Inputs - Side 1/Side 2: 2/2
Packaging: Tube
Data Rate: 80MBd
detail: General Purpose Digital Isolator 1500Vrms 2 Channel 80MBd 1.6kV/µs (Typ) CMTI 28-SOIC (0.295", 7.50mm Width), 12 Leads
