دیتاشیت ADP7159ARDZ-02-R7
مشخصات دیتاشیت
| نام دیتاشیت | ADP7159 |
|---|---|
| حجم فایل | 1065.044 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 23 |
دانلود دیتاشیت ADP7159 |
ADP7159 Datasheet |
|---|
مشخصات
- Manufacturer: Analog Devices Inc.
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Output Configuration: Positive
- Output Type: Adjustable
- Number of Regulators: 1
- Voltage - Input (Max): 5.5V
- Voltage - Output (Min/Fixed): 1.2V
- Voltage - Output (Max): 2.3V
- Voltage Dropout (Max): 0.28V @ 2A
- Current - Output: 2A
- Current - Quiescent (Iq): 8mA
- Current - Supply (Max): 14mA
- PSRR: 61dB ~ 45dB (1kHz ~ 1MHz)
- Control Features: Enable
- Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
- Supplier Device Package: 8-SOIC-EP
- Base Part Number: ADP7159
- detail: Linear Voltage Regulator IC 1 Output 2A 8-SOIC-EP
