PT78NR206S دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت PT78NR206S	دانلود دیتاشیت

Series: PT78NR200 (12W)
Type: Non-Isolated PoL Module
Voltage - Input (Min): 9V
Voltage - Output 3: -
Applications: ITE (Commercial)
Number of Outputs: 1
Package / Case: 3-SMD Module
Voltage - Output 2: -
Part Status: Obsolete
Voltage - Input (Max): 15V
Mounting Type: Surface Mount
Size / Dimension: 1.01" L x 0.93" W x 0.41" H (25.7mm x 23.6mm x 10.4mm)
Voltage - Output 1: -6V
Base Part Number: PT78NR2
Manufacturer: Texas Instruments
Operating Temperature: 0°C ~ 85°C
Efficiency: 78%
Packaging: Tray
Current - Output (Max): 1.8A
Features: OTP, SCP
detail: Non-Isolated PoL Module DC DC Converter 1 Output -6V 1.8A 9V - 15V Input
