- TIBPAL22V10-7C
TIBPAL22V10-7CFN Datasheet
Datasheet specifications
| Datasheet's name | TIBPAL22V10-7C |
|---|---|
| File size | 288.84 KB |
| File type | |
| Number of pages | 21 |
Download Datasheet TIBPAL22V10-7C |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Series: IMPACT-X™ PAL®
- Programmable Type: PAL
- Number of Macrocells: 10
- Part Status: Obsolete
- Mounting Type: Surface Mount
- Manufacturer: Texas Instruments
- Speed: 7.5ns
- Voltage - Input: 5V
- Package / Case: 28-LCC (J-Lead)
- Packaging: Tube
- Base Part Number: TIBPAL22
- Supplier Device Package: 28-PLCC (11.51x11.51)
- detail: IMPACT-X™ PAL® Programmable Logic Device (PLD) IC 10 Macrocells 28-PLCC (11.51x11.51)
