دیتاشیت AD8582ARZ-REEL

AD8582

مشخصات دیتاشیت

نام دیتاشیت AD8582
حجم فایل 316.619 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت AD8582

AD8582 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices AD8582ARZ-REEL
  • Interface: Parallel
  • resolution: 12
  • output type: Voltage-缓冲
  • built-up time: 16us
  • Supply Voltage: 5V
  • Integral nonlinearity: ±0.75LSB
  • Operating Temperature: -40°C~+85°C
  • Package: SOIC-24-300mil
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Number of Bits: 12
  • Number of D/A Converters: 2
  • Settling Time: 16µs (Typ)
  • Differential Output: No
  • Data Interface: Parallel
  • Reference Type: Internal
  • Voltage - Supply, Analog: 5V
  • Voltage - Supply, Digital: 5V
  • INL/DNL (LSB): ±0.75, ±0.75
  • Architecture: R-2R
  • Package / Case: 24-SOIC (0.295", 7.50mm Width)
  • Supplier Device Package: 24-SOIC
  • Mounting Type: Surface Mount
  • Base Part Number: AD8582
  • detail: 12 Bit Digital to Analog Converter 2 24-SOIC
