دیتاشیت ADG1436TRUZ-EPR7
مشخصات دیتاشیت
| نام دیتاشیت |
ADG1436-EP
|
| حجم فایل |
252.663
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
10
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Analog Devices ADG1436TRUZ-EPR7
-
Supply Voltage:
5V~16.5V
-
Switch Circuit:
SPDT(SPDT)
-
Number of Channels:
2
-
On-State Resistance (Max):
1.8Ω
-
Package:
TSSOP-16
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Multiplexer/Demultiplexer Circuit:
2:1
-
Number of Circuits:
2
-
Channel-to-Channel Matching (ΔRon):
100mOhm
-
Voltage - Supply, Single (V+):
5V, ±4.5V ~ 16.5V, ±16.5V
-
Voltage - Supply, Dual (V±):
5V, ±4.5V ~ 16.5V, ±16.5V
-
Switch Time (Ton, Toff) (Max):
-, -
-
-3db Bandwidth:
110MHz
-
Charge Injection:
-20pC
-
Channel Capacitance (CS(off), CD(off)):
23pF, 50pF
-
Current - Leakage (IS(off)) (Max):
550pA
-
Crosstalk:
-80dB @ 100kHz
-
Operating Temperature:
-55°C ~ 125°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
16-TSSOP (0.173", 4.40mm Width)
-
Supplier Device Package:
16-TSSOP
-
detail:
2 Circuit IC Switch 2:1 1.8Ohm 16-TSSOP
