دیتاشیت AD5292SRUZ-20-EP
مشخصات دیتاشیت
| نام دیتاشیت |
AD5292-EP
|
| حجم فایل |
448.015
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
16
|
مشخصات
-
RoHS:
true
-
Category:
ADC/DAC/Data Conversion/Digital Potentiometers
-
Datasheet:
Analog Devices AD5292SRUZ-20-EP
-
Precision:
±1%
-
Interface Type:
SPI
-
Number of Taps:
1024
-
Supply Voltage:
9V~33V;9V~16.5V
-
Number of Channels:
1
-
Operating Temperature:
-55°C~+125°C
-
Resistance Value (Ohms):
20kΩ
-
Temperature Coefficient (Typ):
35ppm/°C
-
Package:
TSSOP-14
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Taper:
Linear
-
Configuration:
Potentiometer
-
Number of Circuits:
1
-
Resistance (Ohms):
20k
-
Interface:
SPI
-
Memory Type:
Non-Volatile
-
Voltage - Supply:
9V ~ 33V, ±9V ~ 16.5V
-
Features:
-
-
Tolerance:
±1%
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
14-TSSOP
-
Package / Case:
14-TSSOP (0.173", 4.40mm Width)
-
Resistance - Wiper (Ohms) (Typ):
60
-
Base Part Number:
AD5292
-
detail:
Digital Potentiometer 20k Ohm 1 Circuit 1024 Taps SPI Interface 14-TSSOP
