دیتاشیت ADUM3402TRWZ-EP-RL

مشخصات دیتاشیت

دانلود دیتاشیت ADuM3400_01_02-EP	ADuM3400_01_02-EP Datasheet

Manufacturer: Analog Devices Inc.
Series: iCoupler®
Packaging: Tape & Reel (TR)
Part Status: Active
Technology: Magnetic Coupling
Type: General Purpose
Isolated Power: No
Number of Channels: 4
Inputs - Side 1/Side 2: 2/2
Channel Type: Unidirectional
Voltage - Isolation: 2500Vrms
Common Mode Transient Immunity (Min): 25kV/µs
Data Rate: 10Mbps
Propagation Delay tpLH / tpHL (Max): 50ns, 50ns
Pulse Width Distortion (Max): 3ns
Rise / Fall Time (Typ): 2.5ns, 2.5ns
Voltage - Supply: 3.135V ~ 5.5V
Operating Temperature: -55°C ~ 125°C
Mounting Type: Surface Mount
Package / Case: 16-SOIC (0.295", 7.50mm Width)
Supplier Device Package: 16-SOIC
Base Part Number: ADUM3402
detail: General Purpose Digital Isolator 2500Vrms 4 Channel 10Mbps 25kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
