دیتاشیت AD5734AREZ-REEL7

AD5724,34,54

مشخصات دیتاشیت

نام دیتاشیت AD5724,34,54
حجم فایل 1310.404 کیلوبایت
نوع فایل pdf
تعداد صفحات 31

دانلود دیتاشیت AD5724,34,54

AD5724,34,54 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: iCMOS®
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Number of Bits: 14
  • Number of D/A Converters: 4
  • Settling Time: 12µs
  • Output Type: Voltage - Buffered
  • Differential Output: No
  • Data Interface: SPI, DSP
  • Reference Type: External
  • Voltage - Supply, Analog: ±4.5V ~ 16.5V
  • Voltage - Supply, Digital: 2.7V ~ 5.5V
  • INL/DNL (LSB): ±4 (Max), ±1 (Max)
  • Architecture: String DAC
  • Operating Temperature: -40°C ~ 85°C
  • Package / Case: 24-TSSOP (0.173", 4.40mm Width) Exposed Pad
  • Supplier Device Package: 24-TSSOP-EP
  • Mounting Type: Surface Mount
  • Base Part Number: AD5734
  • detail: 14 Bit Digital to Analog Converter 4 24-TSSOP-EP
