دیتاشیت MIC94072YC6-TR
مشخصات دیتاشیت
| نام دیتاشیت |
MIC94070-73
|
| حجم فایل |
826.191
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
11
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Power Distribution Switches
-
Datasheet:
Microchip Tech MIC94072YC6-TR
-
Input Voltage:
1.7V~5.5V
-
Output Current:
1.2A
-
Number of Outputs:
1
-
Resistor On-State:
120mΩ
-
Operating Temperature -:
-40°C~+125°C
-
Package:
SC-70-6
-
Manufacturer:
Microchip Tech
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Switch Type:
General Purpose
-
Ratio - Input:Output:
1:1
-
Output Configuration:
High Side
-
Output Type:
P-Channel
-
Interface:
On/Off
-
Voltage - Load:
1.7V ~ 5.5V
-
Voltage - Supply (Vcc/Vdd):
Not Required
-
Current - Output (Max):
1.2A
-
Rds On (Typ):
120mOhm
-
Input Type:
Non-Inverting
-
Features:
Slew Rate Controlled
-
Fault Protection:
-
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
SC-70-6
-
Package / Case:
6-TSSOP, SC-88, SOT-363
-
Base Part Number:
MIC94072
-
detail:
Power Switch/Driver 1:1 P-Channel 1.2A SC-70-6
