دیتاشیت AD7177-2BRUZ-RL7
مشخصات دیتاشیت
| نام دیتاشیت |
AD7177-2
|
| حجم فایل |
947.966
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
60
|
مشخصات
-
RoHS:
true
-
Category:
ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
-
Datasheet:
Analog Devices AD7177-2BRUZ-RL7
-
Interface:
SPI;DSP
-
resolution:
32Bit
-
Supply Voltage:
2.5V~5.5V
-
differential input:
Yes
-
number of channels:
2;4
-
sampling frequency:
10kHz
-
Operating Temperature:
-40°C~+105°C
-
Package:
TSSOP-24
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Discontinued at Digi-Key
-
Number of Bits:
32
-
Sampling Rate (Per Second):
10k
-
Number of Inputs:
2, 4
-
Input Type:
Differential, Single Ended
-
Data Interface:
SPI, DSP
-
Configuration:
MUX-ADC
-
Ratio - S/H:ADC:
-
-
Number of A/D Converters:
1
-
Architecture:
Sigma-Delta
-
Reference Type:
External, Internal
-
Voltage - Supply, Analog:
2.5V ~ 5.5V
-
Voltage - Supply, Digital:
2.5V ~ 5.5V
-
Features:
Temperature Sensor
-
Package / Case:
24-TSSOP (0.173", 4.40mm Width)
-
Supplier Device Package:
24-TSSOP
-
Mounting Type:
Surface Mount
-
Base Part Number:
AD7177
-
detail:
32 Bit Analog to Digital Converter 2, 4 Input 1 Sigma-Delta 24-TSSOP
