دیتاشیت AD824ARZ-14-3V-RL
مشخصات دیتاشیت
| نام دیتاشیت | AD824 |
|---|---|
| حجم فایل | 347.992 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت AD824 |
AD824 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/FET InputAmplifiers
- Datasheet: Analog Devices AD824ARZ-14-3V-RL
- Rail To Rail: 轨到轨输出
- Output Current: -
- Supply Voltage: 3V~30V
- Number of Circuits: 4
- Operating Temperature: -40°C~+85°C
- Current - Input Bias(Ib): 4pA
- Gain Bandwidth Product(GBP): 2MHz
- Voltage - Input Offset(Vos): 500uV
- Common Mode Rejection Ratio (CMRR): -
- Package: SOP-14
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Amplifier Type: J-FET
- Output Type: Rail-to-Rail
- Slew Rate: 2V/µs
- Gain Bandwidth Product: 2MHz
- -3db Bandwidth: 2MHz
- Current - Input Bias: 4pA
- Voltage - Input Offset: 500µV
- Current - Supply: 560µA
- Current - Output / Channel: 12mA
- Voltage - Supply, Single/Dual (±): 3V ~ 30V, ±1.5V ~ 15V
- Mounting Type: Surface Mount
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 14-SOIC
- Base Part Number: AD824
- detail: J-FET Amplifier 4 Circuit Rail-to-Rail 14-SOIC
