دیتاشیت MCP1825T-5002E/DC

مشخصات دیتاشیت

MCP1825T-5002E/DC	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Microchip Tech MCP1825T-5002E/DC
Output Current: 500mA
Output Voltage: 5V
Dropout Voltage: 0.35V@(500mA)
Output Polarity: positive
Number of Outputs: 1
Maximum Input Voltage: 6V
Operating Temperature: -40°C~+125°C
Quiescent Current (Ground Current): 220uA
Power Supply Rejection Ratio (PSRR): 60dB@(100Hz)
Package: SOT-223-5
Manufacturer: Microchip Tech
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Output Type: Fixed
Number of Regulators: 1
Voltage - Input (Max): 6V
Voltage - Output (Min/Fixed): 5V
Voltage - Output (Max): -
Voltage Dropout (Max): 0.35V @ 500mA
Current - Output: 500mA
Current - Quiescent (Iq): 220µA
PSRR: 60dB (100Hz)
Control Features: Enable, Power Good
Protection Features: Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Mounting Type: Surface Mount
Package / Case: SOT-223-6
Supplier Device Package: SOT-223-5
Base Part Number: MCP1825
detail: Linear Voltage Regulator IC 1 Output 500mA SOT-223-5
