دیتاشیت AD524ARZ-16-REEL7
مشخصات دیتاشیت
| نام دیتاشیت | AD524 |
|---|---|
| حجم فایل | 589.893 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 25 |
دانلود دیتاشیت AD524 |
AD524 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Instrumentation OpAmps
- Datasheet: Analog Devices AD524ARZ-16-REEL7
- -3db Bandwidth: 1MHz
- Number of Circuits: 1
- Operating Temperature: -25°C~+85°C
- Current - Input Bias(Ib): 50nA
- Gain Bandwidth Product(GBP): 1MHz
- Voltage - Input Offset(Vos): 250uV
- Package: SOP-16-300mil
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Amplifier Type: Instrumentation
- Output Type: -
- Slew Rate: 5V/µs
- Gain Bandwidth Product: 1MHz
- Current - Input Bias: 50nA
- Voltage - Input Offset: 250µV
- Current - Supply: 3.5mA
- Voltage - Supply, Single/Dual (±): ±6V ~ 18V
- Mounting Type: Surface Mount
- Package / Case: 16-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 16-SOIC
- Base Part Number: AD524
- detail: Instrumentation Amplifier 1 Circuit 16-SOIC
