AD7605-4BSTZ-RL Datasheet

AD7605-4BSTZ-RL

Datasheet specifications

Datasheet's name AD7605-4BSTZ-RL
File size 107.802 KB
File type pdf
Number of pages 27

Download Datasheet AD7605-4BSTZ-RL

Download Datasheet

Other documentations

AD7605-4 27 pages

Technical specifications

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Analog Devices AD7605-4BSTZ-RL
  • Interface: Parallel;SPI
  • resolution: 16Bit
  • Supply Voltage: 5V
  • number of channels: 4
  • sampling frequency: 300kHz
  • Operating Temperature: -40°C~+85°C
  • Package: LQFP-64(10x10)
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Number of Bits: 16
  • Sampling Rate (Per Second): 300k
  • Number of Inputs: 4
  • Input Type: Single Ended
  • Data Interface: Parallel, SPI
  • Configuration: S/H-MUX-ADC
  • Ratio - S/H:ADC: 1:1
  • Number of A/D Converters: 1
  • Architecture: SAR
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 5V
  • Voltage - Supply, Digital: 2.3V ~ 5.25V
  • Features: Simultaneous Sampling
  • Package / Case: 64-LQFP
  • Supplier Device Package: 64-LQFP (10x10)
  • Mounting Type: Surface Mount
  • Base Part Number: AD7605
  • detail: 16 Bit Analog to Digital Converter 4 Input 1 SAR 64-LQFP (10x10)
