دیتاشیت AD7714ARSZ-3REEL

AD7714

مشخصات دیتاشیت

نام دیتاشیت AD7714
حجم فایل 299.742 کیلوبایت
نوع فایل pdf
تعداد صفحات 40

دانلود دیتاشیت AD7714

AD7714 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Analog Devices AD7714ARSZ-3REEL
  • Interface: SPI;DSP
  • resolution: 24Bit
  • Supply Voltage: 3V~3.6V
  • differential input: Yes
  • number of channels: 3;5
  • sampling frequency: 1kHz
  • Operating Temperature: -40°C~+85°C
  • Package: SSOP-28-208mil
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Number of Bits: 24
  • Sampling Rate (Per Second): 1k
  • Number of Inputs: 3, 5
  • Input Type: Differential, Pseudo-Differential
  • Data Interface: SPI, DSP
  • Configuration: MUX-PGA-ADC
  • Ratio - S/H:ADC: -
  • Number of A/D Converters: 1
  • Architecture: Sigma-Delta
  • Reference Type: External
  • Voltage - Supply, Analog: 3V ~ 3.6V
  • Voltage - Supply, Digital: 3V ~ 5.25V
  • Features: PGA
  • Package / Case: 28-SSOP (0.209", 5.30mm Width)
  • Supplier Device Package: 28-SSOP
  • Mounting Type: Surface Mount
  • Base Part Number: AD7714
  • detail: 24 Bit Analog to Digital Converter 3, 5 Input 1 Sigma-Delta 28-SSOP
