دیتاشیت MIC5524-3.3YMT-T5
مشخصات دیتاشیت
| نام دیتاشیت | MIC5524 |
|---|---|
| حجم فایل | 605.632 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 13 |
دانلود دیتاشیت MIC5524 |
MIC5524 Datasheet |
|---|
مشخصات
- Manufacturer: Microchip Technology
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 5.5V
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.5V @ 500mA
- Current - Output: 500mA
- Current - Quiescent (Iq): 55µA
- PSRR: 80dB ~ 65dB (100Hz ~ 1kHz)
- Control Features: Enable
- Protection Features: Over Current, Over Temperature
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 4-UDFN Exposed Pad
- Supplier Device Package: 4-TDFN (1x1)
- Base Part Number: MIC5524-3.3
- detail: Linear Voltage Regulator IC 1 Output 500mA 4-TDFN (1x1)
