دیتاشیت HMC1160LP5ETR

مشخصات دیتاشیت

دانلود دیتاشیت HMC1160LP5E	HMC1160LP5E Datasheet

RoHS: true
Category: Radio Frequency Chip/Antenna/Voltage Controlled Oscillators (VCO)
Datasheet: Analog Devices HMC1160LP5ETR
supply voltage: 5V
operating temperature: -40°C~+85°C
Package: LFCSP-32
Manufacturer: Analog Devices
Series: -
Packaging: Tape & Reel (TR)
Part Status: Active
Frequency Range: 4.225 ~ 4.65GHz, 8.45 ~ 9.30GHz
Frequency - Center: 4.4375GHz, 8.875GHz
Voltage - Supply: 5V
Tuning Voltage (VDC): 2V ~ 13V
2nd Harmonic, Typ (dBc): 18
Icc Max: 325mA
Pushing (MHz/V): 5.5
Power (dBm): 4±4, 13±4
Phase Noise Typ (dBc/Hz): -110
Package / Case: 32-VFQFN Exposed Pad, CSP
Size / Dimension: 0.197" L x 0.197" W (5.00mm x 5.00mm)
Height: 0.039" (1.00mm)
Base Part Number: HMC1160
detail: 4.4375GHz, 8.875GHz Center Frequency 2V ~ 13V Voltage Controlled Oscillator 4±4, 13±4 dBm 18 2nd Harmonic, Typ (dBc)
