دیتاشیت AD5541ABCPZ-1-RL7

AD5541A

مشخصات دیتاشیت

نام دیتاشیت AD5541A
حجم فایل 438.984 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت AD5541A

AD5541A Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices AD5541ABCPZ-1-RL7
  • Interface: SPI;DSP
  • Resolution: 16Bit
  • Output Type: Voltage-非缓冲
  • Settling Time: 1us
  • Supply Voltage: 2.7V~5.5V
  • Integral nonlinearity: ±0.5LSB
  • Operating Temperature: -40°C~+125°C
  • Package: LFCSP-8
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • Number of Bits: 16
  • Number of D/A Converters: 1
  • Differential Output: No
  • Data Interface: SPI, DSP
  • Reference Type: External
  • Voltage - Supply, Analog: 2.7V ~ 5.5V
  • Voltage - Supply, Digital: 2.7V ~ 5.5V
  • INL/DNL (LSB): ±0.5, ±0.5
  • Architecture: R-2R
  • Package / Case: 8-WFDFN Exposed Pad, CSP
  • Supplier Device Package: 8-LFCSP-WD (3x3)
  • Mounting Type: Surface Mount
  • Base Part Number: AD5541
  • detail: 16 Bit Digital to Analog Converter 1 8-LFCSP-WD (3x3)
