دیتاشیت AD9238BCPZ-20
مشخصات دیتاشیت
| نام دیتاشیت |
AD9238
|
| حجم فایل |
1341.302
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
48
|
مشخصات
-
Manufacturer:
Analog Devices Inc.
-
Series:
-
-
Packaging:
Tray
-
Part Status:
Active
-
Number of Bits:
12
-
Sampling Rate (Per Second):
20M
-
Number of Inputs:
2
-
Input Type:
Differential, Single Ended
-
Data Interface:
Parallel
-
Configuration:
S/H-ADC
-
Ratio - S/H:ADC:
1:1
-
Number of A/D Converters:
2
-
Architecture:
Pipelined
-
Reference Type:
External, Internal
-
Voltage - Supply, Analog:
2.7V ~ 3.6V
-
Voltage - Supply, Digital:
2.25V ~ 3.6V
-
Features:
Simultaneous Sampling
-
Operating Temperature:
-40°C ~ 85°C
-
Package / Case:
64-VFQFN Exposed Pad, CSP
-
Supplier Device Package:
64-LFCSP-VQ (9x9)
-
Mounting Type:
Surface Mount
-
Base Part Number:
AD9238
-
detail:
12 Bit Analog to Digital Converter 2 Input 2 Pipelined 64-LFCSP-VQ (9x9)
