دیتاشیت AD7944BCPZ-RL7

AD7944

مشخصات دیتاشیت

نام دیتاشیت AD7944
حجم فایل 625.948 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت AD7944

AD7944 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Analog Devices AD7944BCPZ-RL7
  • Interface: SPI;DSP
  • resolution: 14Bit
  • Supply Voltage: 2.375V~2.625V
  • number of channels: 1
  • sampling frequency: 2.5MHz
  • Operating Temperature: -40°C~+85°C
  • Package: LFCSP-20
  • Manufacturer: Analog Devices
  • Series: PulSAR®
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Number of Bits: 14
  • Sampling Rate (Per Second): 2.5M
  • Number of Inputs: 1
  • Input Type: Pseudo-Differential
  • Data Interface: SPI, DSP
  • Configuration: S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Number of A/D Converters: 1
  • Architecture: SAR
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 2.375V ~ 2.625V
  • Voltage - Supply, Digital: 2.375V ~ 2.625V
  • Features: -
  • Package / Case: 20-WFQFN Exposed Pad, CSP
  • Supplier Device Package: 20-LFCSP-WQ (4x4)
  • Mounting Type: Surface Mount
  • Base Part Number: AD7944
  • detail: 14 Bit Analog to Digital Converter 1 Input 1 SAR 20-LFCSP-WQ (4x4)
