AD9246BCPZRL7-80 Datasheet
Datasheet specifications
| Datasheet's name | AD9246BCPZRL7-80 |
|---|---|
| File size | 113.127 KB |
| File type | |
| Number of pages | 44 |
Download Datasheet AD9246BCPZRL7-80 |
Download Datasheet |
|---|
Other documentations
AD9246 44 pages
Technical specifications
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Analog Devices AD9246BCPZRL7-80
- Interface: Parallel
- resolution: 14Bit
- Supply Voltage: 1.7V~1.9V
- differential input: Yes
- number of channels: 1
- sampling frequency: 80MHz
- Operating Temperature: -40°C~+85°C
- Package: LFCSP-48
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Number of Bits: 14
- Sampling Rate (Per Second): 80M
- Number of Inputs: 1
- Input Type: Differential, Single Ended
- Data Interface: Parallel
- Configuration: S/H-ADC
- Ratio - S/H:ADC: 1:1
- Number of A/D Converters: 1
- Architecture: Pipelined
- Reference Type: Internal
- Voltage - Supply, Analog: 1.7V ~ 1.9V
- Voltage - Supply, Digital: 1.7V ~ 3.6V
- Features: -
- Package / Case: 48-VFQFN Exposed Pad, CSP
- Supplier Device Package: 48-LFCSP-VQ (7x7)
- Mounting Type: Surface Mount
- Base Part Number: AD9246
- detail: 14 Bit Analog to Digital Converter 1 Input 1 Pipelined 48-LFCSP-VQ (7x7)
