دیتاشیت ADUC845BSZ62-5-RL
مشخصات دیتاشیت
| نام دیتاشیت | ADUC845,847,848 |
|---|---|
| حجم فایل | 1097.997 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 109 |
دانلود دیتاشیت ADUC845,847,848 |
ADUC845,847,848 Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: -
- CPU Core: 51Series
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: Yes
- ADC (Bit): 24bit
- DAC (Bit): 12bit;16bit
- Datasheet: Analog Devices ADUC845BSZ62-5-RL
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 12.58MHz
- GPIO Ports Number: 34
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM;WDT
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 62KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 4.75V~5.25V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+125°C
- Secure Digital Input and Output: -
- Package: MQFP-52(10x10)
- Manufacturer: Analog Devices
- Series: MicroConverter® ADuC8xx
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Core Processor: 8052
- Core Size: 8-Bit
- Speed: 12.58MHz
- Connectivity: I²C, SPI, UART/USART
- Peripherals: POR, PSM, PWM, Temp Sensor, WDT
- Number of I/O: 34
- Program Memory Size: 62KB (62K x 8)
- EEPROM Size: 4K x 8
- Voltage - Supply (Vcc/Vdd): 4.75V ~ 5.25V
- Data Converters: A/D 10x24b; D/A 1x12b, 2x16b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 52-QFP
- Supplier Device Package: 52-MQFP (10x10)
- Base Part Number: ADUC845
- detail: 8052 MicroConverter® ADuC8xx Microcontroller IC 8-Bit 12.58MHz 62KB (62K x 8) FLASH 52-MQFP (10x10)
