دیتاشیت MCP16251T-I/MNY
مشخصات دیتاشیت
| نام دیتاشیت | MCP16251/52 Datasheet |
|---|---|
| حجم فایل | 866.896 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 32 |
دانلود دیتاشیت MCP16251/52 Datasheet |
MCP16251/52 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: boost converterType
- Topology: Boost
- Datasheet: Microchip Tech MCP16251T-I/MNY
- Output Type: Adjustable
- Input Voltage: 0.82V~5.5V
- Output Voltage: 1.8V~5.5V
- Number of Outputs: 1
- Switching Frequency: 500kHz
- Output Current (Max): 100mA
- Operating Temperature: -40°C~+85°C@(TJ)
- Synchronous Rectification: Yes
- Package: DFN-8-EP(2x3)
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Output Configuration: Positive
- Voltage - Input (Min): 0.82V
- Voltage - Input (Max): 5.5V
- Voltage - Output (Min/Fixed): 1.8V
- Voltage - Output (Max): 5.5V
- Current - Output: 100mA (Switch)
- Frequency - Switching: 500kHz
- Synchronous Rectifier: Yes
- Mounting Type: Surface Mount
- Package / Case: 8-WFDFN Exposed Pad
- Supplier Device Package: 8-TDFN (2x3)
- Base Part Number: MCP16251
- detail: Boost Switching Regulator IC Positive Adjustable 1.8V 1 Output 100mA (Switch) 8-WFDFN Exposed Pad
