MIC2605YML-TR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MIC2605YML-TR	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: boost converterType
Topology: Boost
Datasheet: Microchip Tech MIC2605YML-TR
Output Type: Adjustable
Input Voltage: 4.5V~20V
Output Voltage: 4.5V~40V
Number of Outputs: 1
Switching Frequency: 1.2MHz
Output Current (Max): 500mA
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: NO
Package: MLF-8
Manufacturer: Microchip Tech
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 4.5V
Voltage - Input (Max): 20V
Voltage - Output (Min/Fixed): 4.5V
Voltage - Output (Max): 40V (Switch)
Current - Output: 500mA (Switch)
Frequency - Switching: 1.2MHz
Synchronous Rectifier: No
Mounting Type: Surface Mount
Package / Case: 8-VFDFN Exposed Pad, 8-MLF®
Supplier Device Package: 8-MLF® (2x2)
Base Part Number: MIC2605
detail: Boost Switching Regulator IC Positive Adjustable 4.5V 1 Output 500mA (Switch) 8-VFDFN Exposed Pad, 8-MLF®
