دیتاشیت LM3503SQ-25/NOPB

LM3503

مشخصات دیتاشیت

نام دیتاشیت LM3503
حجم فایل 1432.351 کیلوبایت
نوع فایل pdf
تعداد صفحات 27

دانلود دیتاشیت LM3503

LM3503 Datasheet

مشخصات

  • Series: -
  • Type: DC DC Regulator
  • Package / Case: 16-WFQFN Exposed Pad
  • Frequency: 1MHz
  • Number of Outputs: 2
  • Topology: Step-Up (Boost)
  • Part Status: Obsolete
  • Mounting Type: Surface Mount
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Internal Switch(s): Yes
  • Applications: Backlight
  • Manufacturer: Texas Instruments
  • Voltage - Supply (Min): 2.5V
  • Current - Output / Channel: 600mA (Switch)
  • Voltage - Output: 25V
  • Packaging: Cut Tape (CT)
  • Base Part Number: LM3503
  • Supplier Device Package: 16-WQFN (4x4)
  • Voltage - Supply (Max): 5.5V
  • Dimming: Analog, PWM
  • detail: LED Driver IC 2 Output DC DC Regulator Step-Up (Boost) Analog, PWM Dimming 600mA (Switch) 16-WQFN (4x4)
