دیتاشیت TC4427COA713

TC442(6, 7, 8)

مشخصات دیتاشیت

نام دیتاشیت TC442(6, 7, 8)
حجم فایل 855.835 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت TC442(6, 7, 8)

TC442(6, 7, 8) Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Microchip Tech TC4427COA713
  • Fall Time: 19ns
  • Load Type: MOSFET
  • Rise Time: 19ns
  • Supply Voltage: 4.5V~18V
  • Number of Drivers: 2
  • Driven Configuration: Low Side
  • Operating Temperature: 0°C~+70°C@(Ta)
  • Peak Output Current(sink): 1.5A
  • Peak Output Current(source): 1.5A
  • Package: SOP-8
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Channel Type: Independent
  • Gate Type: N-Channel, P-Channel MOSFET
  • Voltage - Supply: 4.5V ~ 18V
  • Logic Voltage - VIL, VIH: 0.8V, 2.4V
  • Current - Peak Output (Source, Sink): 1.5A, 1.5A
  • Input Type: Non-Inverting
  • Rise / Fall Time (Typ): 19ns, 19ns
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • Base Part Number: TC4427
  • detail: Low-Side Gate Driver IC Non-Inverting 8-SOIC
