دیتاشیت MIC3490-2.5YM5-TR
مشخصات دیتاشیت
| نام دیتاشیت | MIC3490 |
|---|---|
| حجم فایل | 848.405 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت MIC3490 |
MIC3490 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Microchip Tech MIC3490-2.5YM5-TR
- Output Current: 100mA
- Output Voltage: 2.5V
- Dropout Voltage: 0.45V@(100mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 36V
- Operating Temperature: -40°C~+125°C@(Tj)
- Quiescent Current (Ground Current): 30uA
- Package: SOT-23-5
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 36V
- Voltage - Output (Min/Fixed): 2.5V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.45V @ 100mA
- Current - Output: 100mA
- Current - Quiescent (Iq): 30µA
- Current - Supply (Max): 2mA
- PSRR: -
- Control Features: Enable
- Protection Features: Over Temperature
- Mounting Type: Surface Mount
- Package / Case: SC-74A, SOT-753
- Supplier Device Package: SOT-23-5
- detail: Linear Voltage Regulator IC 1 Output 100mA SOT-23-5
