دیتاشیت AD9656BCPZRL7-125
مشخصات دیتاشیت
| نام دیتاشیت | AD9656 |
|---|---|
| حجم فایل | 1168.004 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 46 |
دانلود دیتاشیت AD9656 |
AD9656 Datasheet |
|---|
مشخصات
- Manufacturer: Analog Devices Inc.
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Number of Bits: 16
- Sampling Rate (Per Second): 125M
- Number of Inputs: 4
- Input Type: Differential
- Data Interface: JESD204B
- Configuration: S/H-ADC
- Ratio - S/H:ADC: 1:1
- Number of A/D Converters: 4
- Architecture: Pipelined
- Reference Type: External, Internal
- Voltage - Supply, Analog: 1.7V ~ 1.9V
- Voltage - Supply, Digital: 1.7V ~ 1.9V
- Features: Simultaneous Sampling
- Operating Temperature: -40°C ~ 85°C
- Package / Case: 56-WFQFN Exposed Pad, CSP
- Supplier Device Package: 56-LFCSP-WQ (8x8)
- Mounting Type: Surface Mount
- Base Part Number: AD9656
- detail: 16 Bit Analog to Digital Converter 4 Input 4 Pipelined 56-LFCSP-WQ (8x8)
