MIC47100 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MIC47100
|
|
حجم فایل
|
745.988
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
13
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Microchip Tech MIC47100-1.2YML-TR
-
Output Current:
1A
-
Output Voltage:
1.2V
-
Dropout Voltage:
0.25V@(1A)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
3.6V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
6uA
-
Package:
MLF-8
-
Manufacturer:
Microchip Tech
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
3.6V
-
Voltage - Output (Min/Fixed):
1.2V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.25V @ 1A
-
Current - Output:
1A
-
Current - Quiescent (Iq):
6µA
-
PSRR:
80dB ~ 45dB (1kHz ~ 500kHz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature, Under Voltage Lockout (UVLO)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-VFDFN Exposed Pad, 8-MLF®
-
Supplier Device Package:
8-MLF® (2x2)
-
Base Part Number:
MIC47100
-
detail:
Linear Voltage Regulator IC 1 Output 1A 8-MLF® (2x2)
