دیتاشیت MCP4921T-E/MS

MCP4901,11,21

مشخصات دیتاشیت

نام دیتاشیت MCP4901,11,21
حجم فایل 3418.463 کیلوبایت
نوع فایل pdf
تعداد صفحات 50

دانلود دیتاشیت MCP4901,11,21

MCP4901,11,21 Datasheet

مشخصات

  • Manufacturer: Microchip Technology
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Number of Bits: 12
  • Number of D/A Converters: 1
  • Settling Time: 4.5µs (Typ)
  • Output Type: Voltage - Buffered
  • Differential Output: No
  • Data Interface: SPI
  • Reference Type: External
  • Voltage - Supply, Analog: 2.7V ~ 5.5V
  • Voltage - Supply, Digital: 2.7V ~ 5.5V
  • INL/DNL (LSB): ±4, ±0.25
  • Architecture: String DAC
  • Operating Temperature: -40°C ~ 125°C
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
  • Supplier Device Package: 8-MSOP
  • Mounting Type: Surface Mount
  • Base Part Number: MCP4921
  • detail: 12 Bit Digital to Analog Converter 1 8-MSOP
