AT86RF232 Preliminary دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | AT86RF232 Preliminary |
|---|---|
| حجم فایل | 4214.404 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 175 |
دانلود دیتاشیت AT86RF232 Preliminary |
دانلود دیتاشیت |
|---|
سایر مستندات
مستندات دیگری یافت نشد!
مشخصات فنی
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
- Data Rate: 250Kbps
- Interface: SPI
- Applications: 802.15.4,General-purpose ISM>1GHz
- Frequency Range: 2.4GHz
- Receive Current: 11.3mA
- Operating Voltage: 1.8V~3.6V
- Operating Temperature: 0°C~+70°C
- Current Of Transmitting: 7.2mA
- Package: QFN-32-EP(5x5)
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: TxRx Only
- RF Family/Standard: 802.15.4, General ISM > 1GHz
- Protocol: 6LoWPAN, Zigbee®
- Modulation: O-QPSK
- Frequency: 2.4GHz
- Data Rate (Max): 250kbps
- Power - Output: 3dBm
- Sensitivity: -100dBm
- Memory Size: 128B SRAM
- Serial Interfaces: SPI
- Voltage - Supply: 1.8V ~ 3.6V
- Current - Receiving: 11.3mA ~ 11.8mA
- Current - Transmitting: 7.2mA ~ 13.8mA
- Mounting Type: Surface Mount
- Package / Case: 32-VFQFN Exposed Pad
- Supplier Device Package: 32-QFN (5x5)
- detail: IC RF TxRx Only 802.15.4, General ISM > 1GHz 6LoWPAN, Zigbee® 2.4GHz 32-VFQFN Exposed Pad
