MCP3421 Datasheet دیتاشیت

MCP3421 Datasheet

مشخصات دیتاشیت

نام دیتاشیت MCP3421 Datasheet
حجم فایل 739.843 کیلوبایت
نوع فایل pdf
تعداد صفحات 42

دانلود دیتاشیت MCP3421 Datasheet

دانلود دیتاشیت

سایر مستندات

MCP3421A2T-E/CH 42 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Microchip Tech MCP3421A3T-E/CH
  • Interface: I2C
  • resolution: 18Bit
  • Supply Voltage: 2.7V~5.5V
  • differential input: Yes
  • number of channels: 1
  • sampling frequency: 3.75Hz
  • Operating Temperature: -40°C~+125°C
  • Package: SOT-23-6
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Number of Bits: 18
  • Sampling Rate (Per Second): 3.75
  • Number of Inputs: 1
  • Input Type: Differential
  • Data Interface: I²C
  • Configuration: PGA-ADC
  • Ratio - S/H:ADC: -
  • Number of A/D Converters: 1
  • Architecture: Sigma-Delta
  • Reference Type: Internal
  • Voltage - Supply, Analog: 2.7V ~ 5.5V
  • Voltage - Supply, Digital: 2.7V ~ 5.5V
  • Features: PGA
  • Package / Case: SOT-23-6
  • Supplier Device Package: SOT-23-6
  • Mounting Type: Surface Mount
  • Base Part Number: MCP3421
  • detail: 18 Bit Analog to Digital Converter 1 Input 1 Sigma-Delta SOT-23-6
