دیتاشیت MIC4606-1YTS-T5

MIC4606

مشخصات دیتاشیت

نام دیتاشیت MIC4606
حجم فایل 2485.244 کیلوبایت
نوع فایل pdf
تعداد صفحات 40

دانلود دیتاشیت MIC4606

MIC4606 Datasheet

مشخصات

  • Manufacturer: Microchip Technology
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Driven Configuration: Full-Bridge
  • Channel Type: Independent
  • Number of Drivers: 4
  • Gate Type: N-Channel MOSFET
  • Voltage - Supply: 5.25V ~ 16V
  • Logic Voltage - VIL, VIH: 0.8V, 2.2V
  • Current - Peak Output (Source, Sink): 1A, 1A
  • Input Type: Non-Inverting
  • High Side Voltage - Max (Bootstrap): 108V
  • Rise / Fall Time (Typ): 20ns, 20ns
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 16-SSOP (0.154", 3.90mm Width)
  • Supplier Device Package: 16-TSSOP
  • Base Part Number: MIC4606
  • detail: Full-Bridge Gate Driver IC Non-Inverting 16-TSSOP
