دیتاشیت ADG774BRQ-REEL

ADG774

مشخصات دیتاشیت

نام دیتاشیت ADG774
حجم فایل 138.602 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت ADG774

ADG774 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Switch Circuit: SPDT
  • Multiplexer/Demultiplexer Circuit: 2:1
  • Number of Circuits: 4
  • On-State Resistance (Max): 2.2Ohm (Typ)
  • Channel-to-Channel Matching (ΔRon): 150mOhm
  • Voltage - Supply, Single (V+): 3V ~ 5V
  • Voltage - Supply, Dual (V±): -
  • Switch Time (Ton, Toff) (Max): 15ns, 8ns
  • -3db Bandwidth: 240MHz
  • Charge Injection: 10pC
  • Channel Capacitance (CS(off), CD(off)): 10pF, 20pF
  • Current - Leakage (IS(off)) (Max): 500pA
  • Crosstalk: -75dB @ 10MHz
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 16-SSOP (0.154", 3.90mm Width)
  • Supplier Device Package: 16-QSOP
  • Base Part Number: ADG774
  • detail: 4 Circuit IC Switch 2:1 2.2Ohm (Typ) 16-QSOP
