دیتاشیت MCP3x6x Errata
مشخصات دیتاشیت
| نام دیتاشیت | MCP3x6x Errata |
|---|---|
| حجم فایل | 157.628 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 4 |
MCP3x6x Errata |
دانلود دیتاشیت |
|---|
سایر مستندات
MCP3561/2/4 108 pages
MCP3561T-E/NC 108 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Microchip Tech MCP3562T-E/NC
- Interface: SPI
- resolution: 24Bit
- Supply Voltage: 2.7V~3.6V
- differential input: Yes
- number of channels: 1
- sampling frequency: 153.6kHz
- Operating Temperature: -40°C~+125°C
- Package: QFN-20-EP(3x3)
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Number of Bits: 24
- Sampling Rate (Per Second): 153.6k
- Number of Inputs: 1
- Input Type: Differential, Single Ended
- Data Interface: SPI
- Configuration: -
- Ratio - S/H:ADC: -
- Number of A/D Converters: 1
- Architecture: Sigma-Delta
- Reference Type: -
- Voltage - Supply, Analog: 2.7V ~ 3.6V
- Voltage - Supply, Digital: -
- Features: Internal Oscillator, PGA, Temperature Sensor
- Package / Case: 20-UFQFN Exposed Pad
- Supplier Device Package: 20-UQFN (3x3)
- Mounting Type: Surface Mount
- detail: 24 Bit Analog to Digital Converter 1 Input 1 Sigma-Delta 20-UQFN (3x3)
