AD8011AR-REEL7 Datasheet

AD8011

Datasheet specifications

Datasheet's name AD8011
File size 224.401 KB
File type pdf
Number of pages 16

Download Datasheet AD8011

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Amplifier Type: Current Feedback
  • Number of Circuits: 1
  • Output Type: -
  • Slew Rate: 3500V/µs
  • -3db Bandwidth: 400MHz
  • Current - Input Bias: 5µA
  • Voltage - Input Offset: 2mV
  • Current - Supply: 1.3mA
  • Current - Output / Channel: 30mA
  • Voltage - Supply, Single/Dual (±): 3V ~ 12V, ±1.5V ~ 6V
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • Base Part Number: AD8011
  • detail: Current Feedback Amplifier 1 Circuit 8-SOIC
