دیتاشیت TL594IPWE4
مشخصات دیتاشیت
| نام دیتاشیت |
TL594
|
| حجم فایل |
1517.725
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
33
|
مشخصات
-
Topology:
Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull
-
Number of Outputs:
2
-
Voltage - Supply (Vcc/Vdd):
7V ~ 40V
-
Base Part Number:
TL594
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Package / Case:
16-TSSOP (0.173", 4.40mm Width)
-
Manufacturer:
Texas Instruments
-
Output Configuration:
Positive
-
Series:
-
-
Supplier Device Package:
16-TSSOP
-
Frequency - Switching:
1kHz ~ 300kHz
-
Part Status:
Obsolete
-
Mounting Type:
Surface Mount
-
Control Features:
Dead Time Control, Frequency Control
-
Clock Sync:
No
-
Serial Interfaces:
-
-
Function:
Step-Up, Step-Down, Step-Up/Step-Down
-
Duty Cycle (Max):
97%
-
Packaging:
Tube
-
Synchronous Rectifier:
No
-
Output Type:
Transistor Driver
-
Output Phases:
1
-
detail:
Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull Regulator Positive Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC 16-TSSOP
