- دیتاشیت DSPIC30F4011T-30I/PT
دیتاشیت DSPIC30F4011T-30I/PT
مشخصات دیتاشیت
| نام دیتاشیت | DSPIC30F4011, 4012 Data Sheet |
|---|---|
| حجم فایل | 3196.57 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 238 |
دانلود دیتاشیت DSPIC30F4011, 4012 Data Sheet |
DSPIC30F4011, 4012 Data Sheet Datasheet |
|---|
مشخصات
- RoHS: true
- CPU Core: PIC
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Watchdog: Yes
- ADC (Bit): 10bit
- Datasheet: Microchip Tech DSPIC30F4011T-30I/PT
- GPIO Ports Number: 30
- Low-Voltage Detect: Yes
- Internal Oscillator: Yes
- Program Storage Size: 48KB
- Operating Voltage Range: 2.5V~5.5V
- Operating Temperature Range: -40°C~+85°C
- Package: TQFP-44(10x10)
- Manufacturer: Microchip Tech
- Series: dsPIC™ 30F
- Packaging: Cut Tape (CT)
- Part Status: Active
- Core Processor: dsPIC
- Core Size: 16-Bit
- Speed: 30 MIPs
- Connectivity: CANbus, I²C, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, Motor Control PWM, QEI, POR, PWM, WDT
- Number of I/O: 30
- Program Memory Size: 48KB (16K x 24)
- Program Memory Type: FLASH
- EEPROM Size: 1K x 8
- RAM Size: 2K x 8
- Voltage - Supply (Vcc/Vdd): 2.5V ~ 5.5V
- Data Converters: A/D 9x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 44-TQFP
- Supplier Device Package: 44-TQFP (10x10)
- Base Part Number: DSPIC30F4011
- detail: dsPIC dsPIC™ 30F Microcontroller IC 16-Bit 30 MIPs 48KB (16K x 24) FLASH 44-TQFP (10x10)
