دیتاشیت ATMEGA64RZAPV-10AU

ATMEGA644/V Summary

مشخصات دیتاشیت

نام دیتاشیت ATMEGA644/V Summary
حجم فایل 721.911 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت ATMEGA644/V Summary

ATMEGA644/V Summary Datasheet

مشخصات

  • RoHS: true
  • Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
  • Data Rate: 250Kbps
  • Datasheet: Microchip Tech ATMEGA64RZAPV-10AU
  • Interface: JTAG,SPI,USART
  • Applications: 802.15.4
  • Frequency Range: 2.4GHz
  • Receive Current: 15.5mA
  • Operating Voltage: 1.8V~3.6V
  • Operating Temperature: -40°C~+85°C
  • Current Of Transmitting: 9.5mA
  • Package: TQFP-44(10x10)
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Tray
  • Part Status: Active
  • Type: TxRx + MCU
  • RF Family/Standard: 802.15.4
  • Protocol: 6LoWPAN, Zigbee®
  • Modulation: O-QPSK
  • Frequency: 2.4GHz
  • Data Rate (Max): 250kbps
  • Power - Output: 3dBm
  • Sensitivity: -101dBm
  • Memory Size: 64kB Flash, 2kB EEPROM, 4kB SRAM
  • Serial Interfaces: JTAG, SPI, USART
  • GPIO: 32
  • Voltage - Supply: 1.8V ~ 3.6V
  • Current - Receiving: 15.5mA
  • Current - Transmitting: 9.5mA ~ 16.5mA
  • Mounting Type: Surface Mount
  • Package / Case: 44-TQFP
  • Supplier Device Package: 44-TQFP (10x10)
  • Base Part Number: ATMEGA64
  • detail: IC RF TxRx + MCU 802.15.4 6LoWPAN, Zigbee® 2.4GHz 44-TQFP
