- SAM3S Datasheet
SAM3S Datasheet Datasheet
Datasheet specifications
| Datasheet's name | SAM3S Datasheet |
|---|---|
| File size | 4898.115 KB |
| File type | |
| Number of pages | 1113 |
Download Datasheet SAM3S Datasheet |
Download Datasheet |
|---|
Other documentations
ATSAM3S4CA-AUR 1113 pages
SAM3S Series Summary 64 pages
Technical specifications
- CAN: -
- I2C: -
- I2S: -
- SPI: -
- RoHS: true
- EEPROM: 256KB
- CPU Core: ARM Cortex-M3
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 48KB
- Watchdog: Yes
- ADC (Bit): -
- DAC (Bit): 12bit
- Datasheet: Microchip Tech ATSAM3S4CA-CUR
- PWM (Bit): -
- 8Bit Timer: -
- UART/USART: -
- 16Bit Timer: -
- 32Bit Timer: -
- Real-Time Clock: -
- CPU Maximum Speed: 64MHz
- GPIO Ports Number: 79
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: DMA;WDT
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 256KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.62V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: TFBGA-100
- Manufacturer: Microchip Tech
- Series: SAM3S
- Packaging: Cut Tape (CT)
- Part Status: Active
- Core Processor: ARM® Cortex®-M3
- Core Size: 32-Bit
- Speed: 64MHz
- Connectivity: EBI/EMI, I²C, Memory Card, SPI, SSC, UART/USART, USB
- Peripherals: Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT
- Number of I/O: 79
- Program Memory Size: 256KB (256K x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 1.62V ~ 3.6V
- Data Converters: A/D 15x10/12b; D/A 2x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 100-TFBGA
- Supplier Device Package: 100-TFBGA (9x9)
- Base Part Number: ATSAM3S4
- detail: ARM® Cortex®-M3 SAM3S Microcontroller IC 32-Bit 64MHz 256KB (256K x 8) FLASH 100-TFBGA (9x9)
