دیتاشیت ATMEGA2564RFR2-ZUR

ATMEGA2564/1284/644RFR2 Summary

مشخصات دیتاشیت

نام دیتاشیت ATMEGA2564/1284/644RFR2 Summary
حجم فایل 197.949 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت ATMEGA2564/1284/644RFR2 Summary

ATMEGA2564/1284/644RFR2 Summary Datasheet

مشخصات

  • Manufacturer: Microchip Technology
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: TxRx + MCU
  • RF Family/Standard: 802.15.4
  • Protocol: Zigbee®
  • Modulation: O-QPSK
  • Frequency: 2.4GHz
  • Data Rate (Max): 2Mbps
  • Power - Output: 3.5dBm
  • Sensitivity: -100dBm
  • Memory Size: 256kB Flash, 8kB EEPROM, 32kB SRAM
  • Serial Interfaces: I²C, JTAG, SPI, USART
  • GPIO: 32
  • Voltage - Supply: 1.8V ~ 3.6V
  • Current - Receiving: 5mA ~ 12.5mA
  • Current - Transmitting: 8mA ~ 14.5mA
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Surface Mount
  • Package / Case: 48-VFQFN Exposed Pad
  • Supplier Device Package: 48-QFN (7x7)
  • Base Part Number: ATMEGA2564RFR2
  • detail: IC RF TxRx + MCU 802.15.4 Zigbee® 2.4GHz 48-VFQFN Exposed Pad
