ADA4850-2YCPZ-R2 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: Analog Devices Inc.
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Amplifier Type: Voltage Feedback
- Number of Circuits: 2
- Output Type: Rail-to-Rail
- Slew Rate: 220V/µs
- -3db Bandwidth: 175MHz
- Current - Input Bias: 2.3µA
- Voltage - Input Offset: 600µV
- Current - Supply: 2.5mA
- Current - Output / Channel: 118mA
- Voltage - Supply, Single/Dual (±): 2.7V ~ 6V
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 16-WFQFN Exposed Pad, CSP
- Supplier Device Package: 16-LFCSP-WQ (3x3)
- Base Part Number: ADA4850
- detail: Voltage Feedback Amplifier 2 Circuit Rail-to-Rail 16-LFCSP-WQ (3x3)
